An illustration of a typical non-renewing DHCP session; each message may be either a broadcast or a unicast, depending on the DHCP client capabilities.[7]
The DHCP employs a connectionless service model, using the User Datagram Protocol (UDP). It is implemented with two UDP port numbers for its operations which are the same as for the BOOTP protocol. UDP port number 67 is the destination port of a server, and UDP port number 68 is used by the client.

DHCP relaying

In small networks, where only one IP subnet is being managed, DHCP clients communicate directly with DHCP servers. However, DHCP servers can also provide IP addresses for multiple subnets. In this case, a DHCP client that has not yet acquired an IP address cannot communicate directly with the DHCP server using IP routing, because it does not have a routable IP address, nor does it know the IP address of a router.

In order to allow DHCP clients on subnets not directly served by DHCP servers to communicate with DHCP servers, DHCP relay agents can be installed on these subnets. The DHCP client broadcasts on the local link; the relay agent receives the broadcast and transmits it to one or more DHCP servers using unicast. The relay agent stores its own IP address in the GIADDR field of the DHCP packet. The DHCP server uses the GIADDR to determine the subnet on which the relay agent received the broadcast, and allocates an IP address on that subnet. When the DHCP server replies to the client, it sends the reply to the GIADDR address, again using unicast. The relay agent then retransmits the response on the local network.
